We are one of the professional container plywood flooring factory from China, we began to produce the Apitong container plywood floorboard since 2010, 10 years until now, we had been worked with numerous of customers around world, you must ever know some of them, example CIMC, MSC, MATEC, MECRC, MSK, etc.
We are one of the professional container plywood flooring factory from China, we began to produce the Apitong container plywood floorboard since 2010, 10 years until now, we had been worked with numerous of customers around world, you must ever know some of them, example CIMC, MSC, MATEC, MECRC, MSK, etc.
Bamboo plywood
3S Bamboo plywood; packing plywood, commercial plywood, Film faced Plywood ,
film faced bamboo plywood, bamboo formwork, bamboo board, bamboo
pannel, Construction Material,film faced formwork panel/bamboo plywood/faux bamboo panel
Size: 1220*2440*(8-20)mm 1830*915*(9-10)mm
Glue: Phenolic glue
Materials: Bamboo
Moisture: ≤10%
Density: ≥0.90g/m3⊥
Water Absorption: ≤10%
Modulus Of Elasticity: //≥7×103N/mm2 ⊥5×103N/mm2
Modulus Of Rupture://≥90N/mm2 //≥60N/mm2
Impact Strength:≥60Kj/m2
Bonding Strength:≥60Kj/m2
Abrasion Value: <0.80g/100r
Using times:10-15times
Preservation Strength://≥60N/mm2 ⊥≥40N/mm2a
Iicl quality container plywood flooring
Bamboo and hardwood mixed material
Bamboo face and back (red, yellow, brown,or black as request)
Glue: WBP (100% Phenolic formaldehyde)
Moisture lower than 12%
28mm thickness
Weight: 60-70kg/pc
Fit for repair container
Max load over 6780N
IICL TB 001 Jan 2019 T6 Pass ISO floorboard strength test at between 6.0 and 7.2 tons
With groove cutting
With report of Testing Certificates of treatment and FSC certificates
Quality Standard
IICL TB 001 - January 02, 2019(Revision 3) - Introduces the requirement shown on 1.9 F & 3.7B
Table 1.9
T7 - Only floorboards manufactured to pass ISO** floor strength test at 7.2 tons and above
T6 - Only floorboards manufactured to pass ISO** floor strength test at between 6.0 and 7.2tons
T5 - Only floorboards manufactured to pass ISO** floor strength test at between 5.0 and 6.0tons
**ISO floor test 1495 - 1 Sixth Edition 2013-07-01- 6.9 Test No. 8
Export Standard
For New Build Container and Repair Container.
Size can do according to customer's request.
1. size: 1220* 2440mm, 1160* 2400mm ( beveled edge/groove)
2. thickness: 28 mm
3. core: all hardwood - red hard wood, keruing, birch, red elm
4. glue: wbp glue
5. weight: 58 - 65 kg/sheet
6. plies: 19 - 21 plies
7. face/back: burma keruing/apitong veneer
8. thickness of f/b:0.4-0.5mm thick as request
9. density: 695-779 kg/m3a
10. grade: A/A , A/B
11. tensile strength: up 6000 N
12. treat:AQIS treatment ,Fumigation Certificate,Test Certificate, Phytosanitary Certificate
13. usage: dry container repairing ,Container Flooring ,container repair
14. Maxload:5tons,6tons, 7.2tons
