Shuttering formwork

Film Faced Plywood /Marine Plywood/ Construction Plywood

1220*2240*(10-20mm),915*1830*(10-20mm)/4*8 ft,3*6ft
Glue: Melamine glue/MR WBP
Core: pine,hardwood,eucalyptus,mixed etc.
Face and Back: Black film, brown film, anti-slip film
Standard Quality:Natural wood face, one time hot pressing
High Quality: Double side film faced, twice hot pressing and sanding
Moisture: 9
Adhesive Force: 0.76/Mpa
Bending Strength Longitudinal: 36/Mpa
Bending Strength Cross: 22/Mpa
Elastic Modulus: Longitudinal: 5981/Mpa
Cross:4850/Mpa
Using time: 6-15 times

Load reference:
13mm  25kg/pc  690pcs/20ft    870pcs/40gp;
14mm   27kg/pc  640pcs/20ft   810pcs/40gp;
15mm   29kg/pc  600pcs/20ft   750pcs/40gp.

Advantage:
1.Adopting the high quality poplar, whole core and first grade, no holes in the middle of plywood after sawing, which can guarantee the toughness of template.
2.Adding the melamine glue from core to face, high glue concentration which can guarantee the glues adhesiveness.
3.manufacturing principles: Each core board is with layer by layer gluing and with high pressure. Layer and layer gluing can fully bond that improve 10-10% bonding

strength, the hot pressure is 120% higher than the heoretical one ,avoiding to reduce pressure to keep the thickness. The turnover of   finished film faced plywood

can be up to 10- 15times,which ensure product be more durable;
4.two times sanding (secondary molding) before film facing ensure the smoothness of the template without burrs and groove marks.

Applications: High- rise construction,building construction, forming concrete,can be widely use for building concrete .

High strength construction wood veneer

Size: 1220*2440mm , 1830*915mm,4*8 ft,3*6ft
Thickness: 12mm~30mm
Glue: Melamine glue/MR WBP
Core: pine,hardwood,eucalyptus,mixed etc.
Face and Back: Black film, brown film, anti-slip film
Standard Quality:Natural wood face, one time hot pressing
High Quality: Double side film faced, twice hot pressing and sanding
Moisture: 9
Adhesive Force: 0.76/Mpa
Bending Strength Longitudinal: 36/Mpa
Bending Strength Cross: 22/Mpa
Elastic Modulus: Longitudinal: 5981/Mpa
Cross:4850/Mpa
Using time: 6-15 times

Advantage:
4.Adopting the high quality poplar, whole core and first grade, no holes in the middle of plywood after sawing, which can guarantee the toughness of template.
5.Adding the melamine glue from core to face, high glue concentration which can guarantee the glues adhesiveness.
6.manufacturing principles: Each core board is with layer by layer gluing and with high pressure. Layer and layer gluing can fully bond that improve 10-10% bonding

strength, the hot pressure is 120% higher than the heoretical one ,avoiding to reduce pressure to keep the thickness. The turnover of   finished film faced plywood

can be up to 10- 15times,which ensure product be more durable;
4.two times sanding (secondary molding) before film facing ensure the smoothness of the template without burrs and groove marks.

Applications: High- rise construction,building construction, forming concrete,can be widely use for building concrete .

Natural horizontal bamboo veneer for interior decoration

OUR 3S bamboo veneer is manufactured from 4-6 years old organically grow FSC certificated mutual bamboo. Always the perfect color, density and strength. It is our aim

that by providing premium quality products constructed from renewable resources, we can make a difference in the future of our planet.

To make ply bamboo veneer, rectangular strips are cut from the bamboo and then boiled to remove sugars. Only premium quality stripes are selected from manufacturing

into veneer plywood. After treatment and drying, a final moisture content of 6-8% is achieved to ensure optimum stability. These bamboo stripe then undergo state of

the art compression using E1-level adhesives which binds them together to form plywood veneer.
Hot sale natural horizontal bamboo veneer for interior decoration

Material: solid bamboo sheet / bamboo woven
Moisture: 7%-10%
Coating: 6-8 coating finish
Formaldehyde Emission: up to E1 standard of Europe
Usage: outdoor,indoor, furniture,suitable for heating
Function:durable,moisture proof,water proof,sound proof, insect resistant, Eco friendly
Installation: float, nail or glue down
Warranty: 25 years of structural guarantee
Packing: carton box, pallet
MOQ: 500 square meter

Construction formwork,

Wooden formwork, Plywood for construction, Shuttering plywood, Shuttering formwork, plywood.
Size: 1220*2440*(12-30)mm    1830*915*(11-30)mm
Glue: Phenolic glue
Material: Pine,Eucalyptus,hardwood
Moisture:9
Density: 750kg/m3
Modulus Of Elasticity:≥5000   ≥4000
Modulus Of Rupture：//≥24/mm2  //≥20/mm2
Bonding Strength：  0.76
Using times： 8-10times

Aluminum Cladded Densified Plywood

Aluminium Cladded Densified Plywood is highly sophisticated plywood used in the flooring of automotive sector. Special quality epoxy resin is used to combine aluminium

with ply board. This plywood has the properties of medium density compreg plywood which gives excellent strength and high mechanical properties to withstand any

adverse condition.

Applications: This type of plywood is also use in Bus Flooring, Factory Flooring, laboratories Flooring.

Calibrated Plywood

Calibrated plywood is a special grade of plywood manufactured by two way pressing system. Assembled core veneers are pressed in hydraulic hot press and then sanded in

imported state of art calibrated machine.
After getting a uniform size panel, it is laminated with face veneer and again sanded with wide belt sander to get the perfect finish. With this process we are able to

get a uniform thickness in plywood with a variation of +- 0.1mm.
Calibrated plywood is ideal for the lamination of laminate.
Calibrated plywood helps in easy working on CNC machines.

Applications: Calibrated plywood is used in Modular Furniture and Modular Kitchen industry.

Chequered Floor Board, truck/bus floors

Densified Chequered floor board is a unique product manufactured by using superior grade phenolic resin. It is medium density compreg plywood, which possesses

excellent strength, durability and all weather resistance. It provides anti-skid, chequered surface, making it ideal for bus flooring.
Using our large boards can reduce the time and labour in laying bus and truck floors. It requires no pre/post treatment at the work-site thereby cutting down costs

considerably. Easy cutting routing, screwing, grooving gives Densified Chequered Floor Board an edge over aluminium and steel floor boards. Densified Chequered Floor

Boards are an ideal blend of low weight, high strength, and high resistance to abrasion and extreme.

Applications:Chequered Floor board is extensively used in bus and truck floors.

Pre-Laminated Plywood

BWR Grade & Marine Grade Plywood pre-laminated with various shades of laminates for the purpose of building, interiors, furniture, bus body interiors etc. This helps

in reducing the cost and time to manufacture various products. This product has been highly recommended by architects.

Applications:Pre laminated plywood is used for Interiors of buildings and bus body.

MR Grade flooring
(Moisture Resistant) plywood is largely used for interiors. This does not get delaminated in warm water (600C) and exhibits good mechanical properties. This is also

dimensionally stable in all weather conditions. It confirms to the standard of IS:303:1989. This plywood is bonded with Melamine Urea Formaldehyde Synthetic Resin.

Sound Insulation Plywood

marine sound insulation plywood which is fully capable to fight noise pollution. This ready to used plywood is manufactured by sandwiching a layer of sound absorbing

material between two plywood sheets. It has the capacity to reduce the noise upto 25 Db.It is light in weight, fire retardant and has high strength to weight ration.

It is easy to work with using conventional wood working tools and can be drilled, milled, trusted and swan to close tolerances.

Applications: Sound Insulation Plywood is use in Trains, Buses, Movie Theaters, Recording Studios, Sound Insulating Partitions etc.
